Wielding the Weapon of Nuclear Expertise: Russia

Leave a reply

Cutting the heart out of a nuclear power plant, the dismantling of a nuclear power plant, is a surgical procedure that only a few specialists are equipped to handle. The process begins by launching plasma-torch-wielding robots into an empty pool surrounded by thick concrete walls. From there, the remote-controlled machines make circular cuts, as if slicing pineapple rings, through a 600-ton steel vessel that contains radiation generated over decades of splitting atoms. These rings are then diced into meter-long pieces and transported via secure convoy to radioactive waste repositories, where they are left to cool down — indefinitely.

Behind the scenes, scores of nuclear engineers, radiation safety experts and state regulators monitor this operation, which can cost upwards of a billion dollars and take years to plan and execute. The expertise needed to pull this off without error is why “there are only a handful of players” in the high-radiation decommissioning (dismantling) business, said Uniper SE’s Michael Baechler, who is supervising the dismantling of Sweden’s Barsebaeck Nuclear Power Plant.

Among the oldest and most experienced is Germany’s Nukem Technologies Engineering Services GmbH, which for decades has offered its unique services in Asia and Africa and across Europe. Nukem engineers helped contain radiation from the destroyed reactors in Chernobyl and Fukushima. They helped lead the clean-up of an atomic-fuel factory in Belgium. In France, the company devised ways to treat waste from the International Thermonuclear Experimental Reactor. With researchers predicting that cleaning up after aging nuclear power plants will evolve into a $125 billion global business in the near future, Nukem should be ideally positioned to capitalize on the moment.

Except for one thing: the company is wholly owned by Rosatom Corp., the Kremlin-controlled nuclear giant, putting it in the center of an uncomfortable standoff…Unlike Germany’s seizure of Russian storage and refining assets after the war with Ukraine, Nukem does not have as much fixed infrastructure to go after. If sanctions were to be imposed, Rosatom might simply close shop or move Nukem’s headquarters to a friendlier jurisdiction… But this presents a problem because “Nukem presides over a large pool of know-how.” Its valuable asset being its 120 mostly German engineers who can work across the nuclear supply chain from the building to the decommissioning of nuclear power plants. The International Atomic Energy Agency has warned of an acute shortage of decommissioning workers.

Excerpt from The Russian nuclear company the West can’t live without, Bloomberg News, May 13, 2023

Imagining Failure: Nuclear Waste on the Beach, California

Leave a reply

But for all the good vibes and stellar sunsets of  San Onofre state beach in California, beneath the surface hides a potential threat: 3.6m lb of nuclear waste from a group of nuclear reactors shut down nearly a decade ago. Decades of political gridlock have left it indefinitely stranded, susceptible to threats including corrosion, earthquakes and sea level rise. The San Onofre reactors are among dozens across the United States phasing out, but experts say they best represent the uncertain future of nuclear energy.

“It’s a combination of failures, really,” said Gregory Jaczko, who chaired the US Nuclear Regulatory Commission (NRC), the top federal enforcer, between 2009 and 2012, of the situation at San Onofre. That waste is the byproduct of the San Onofre Nuclear Generating Station (Songs), three nuclear reactors primarily owned by the utility Southern California Edison (SCE) that has shut down….

Since there is not central repository for the final disposition of nuclear wasted in the United States,  the California Coastal Commission approved in 2015 the construction of an installation at San Onofre to store it until 2035. In August 2020, workers concluded the multi-year burial process, loading the last of 73 canisters of waste into a concrete enclosure. San Onofre is not the only place where waste is left stranded. As more nuclear sites shut down, communities across the country are stuck with the waste left behind. Spent fuel is stored at 76 reactor sites in 34 states….

At San Onofre, the waste is buried about 100ft from the shoreline, along the I-5 highway, one of the nation’s busiest thoroughfares, and not far from a pair of faults that experts say could generate a 7.4 magnitude earthquake. Another potential problem is corrosion. In its 2015 approval, the Coastal Commission noted the site could have a serious impact on the environment in case of coastal flooding and erosion hazards beyond its design capacity,

Concerns have also been raised about government oversight of the site. Just after San Onofre closed, SCE began seeking exemptions from the NRC’s operating rules for nuclear plants. The utility asked and received permission to loosen rules on-site, including those dealing with record-keeping, radiological emergency plans for reactors, emergency planning zones and on-site staffing.

San Onofre isn’t the only closed reactor to receive exemptions to its operating licence. The NRC’s regulations historically focused on operating reactors and assumed that, when a reactor shut down, the waste would be removed quickly.

It’s true that the risk of accidents decreases when a plant isn’t operating, said Dave Lochbaum of the Union of Concerned Scientists. But adapting regulations through exemptions greatly reduces public transparency, he argued. “Exemptions are wink-wink, nudge-nudge deals with the NRC,” he said. “In general, it’s not really a great practice,” former NRC chair Jaczko said about the exemptions. “If the NRC is regulating by exemption, it means that there’s something wrong with the rules … either the NRC believes the rules are not effective, and they’re not really useful, or the NRC is not holding the line where the NRC should be holding line,” he said…

It’s worth considering how things fail, though, argued Rod Ewing, nuclear security professor at Stanford University’s center for international security and cooperation, and author of a 2021 report about spent nuclear waste that focuses on San Onofre. “The problem with our safety analysis approach is we spend a lot of time proving things are safe. We don’t spend much time imagining how systems will fail,” he said. “And I think the latter is what’s most important.”

Excerpts from Kate Mishkin, ‘A combination of failures:’ why 3.6m pounds of nuclear waste is buried on a popular California beach, Guardian, Aug.

How to Make Money out of the Nuclear Waste Mess

Leave a reply

Companies specializing in the handling of radioactive material are buying retired U.S. nuclear reactors from utilities and promising to clean them up and demolish them in dramatically less time than usual — eight years instead of 60, in some cases.  Turning nuclear plants over to outside companies and decommissioning them on such a fast track represents a completely new approach in the United States, never before carried to completion in this country, and involves new technology as well…

Once a reactor is shut down, the radioactive mess must be cleaned up, spent nuclear fuel packed for long-term storage and the plant itself dismantled. The most common approach can last decades, with the plant placed in a long period of dormancy while radioactive elements slowly decay.  Spent fuel rods that can no longer sustain a nuclear reaction remain radioactive and still generate substantial heat. They are typically placed in pools of water to cool, staying there for at least five years, with 10 years the industry norm, according to the Nuclear Regulatory Commission. After that, they are removed and placed in giant cylindrical casks, typically made of steel and encased in concrete.

But Holtec International, which in the past year has been buying up several retired or soon-to-be-retired nuclear plants in the U.S., has designed a cask it says can accept spent fuel after only two years of cooling.  Holtec struck a deal last year to buy Oyster Creek in Forked River, New Jersey, from its owner, Exelon Generation.  It also has deals in place to buy several plants owned by Entergy Corp., including: Pilgrim, in historic Plymouth, Massachusetts, closing May 31; Palisades, in Covert, Michigan, set to shut down in 2022 ; and two reactors expected to close within two years at Indian Point in Buchanan, New York….  NorthStar Group Services, a specialist in nuclear demolition, completed the purchase of Vermont Yankee from Entergy with plans for its accelerated decommissioning.

The companies jumping into the business believe they can make in profit….Holtec will inherit the multibillion-dollar decommissioning trust funds set up by the utilities for the plants’ eventual retirement. , The company would be able to keep anything left over in each fund after the plant’s cleanup. By Holtec’s accounting, for instance, the Pilgrim decommissioning will cost an estimated $1.13 billion, leaving $3.6 million in the fund.  Holtec and Northstar are also banking on the prospect of recouping money from the federal government for storing spent fuel during and after the decommissioning, because there is no national disposal site for high-level nuclear waste…

Holtec has come under scrutiny over its role in a mishap in August 2018 during the somewhat less aggressive decommissioning of the San Onofre plant in Southern California, where two reactors were retired in 2013 and the estimated completion date is 2030….Holtec contractors were lowering a 45-ton spent fuel cask into an underground storage vault at San Onofre when it became misaligned and nearly plunged 18 feet, investigators said. No radiation was released.  Federal regulators fined Southern California Edison, the plant’s owner, $116,000, and an investigation found that some Holtec procedures had been inadequate or not properly followed.

BOB SALSBERG , Speedy reactor cleanups may carry both risks and rewards, Associated Press, May 21, 2019

What to Do with 56 000 Drums of Nuclear Waste: Japan

Leave a reply

At least 1.9 trillion yen ($17.12 billion) will be needed for the planned scrapping of 79 nuclear facilities, including the failed Monju prototype fast-breeder reactor, according to the Japan Atomic Energy Agency (JAEA).

However, the JAEA’s estimate, released on Dec. 26, 2018 does not include maintenance expenses for the facilities nor costs to deal with leftover uranium and plutonium, meaning the actual tally could increase by hundreds of billions of yen.  State subsidies account for the bulk of the JAEA’s budget, so taxpayers will likely foot most of the bill.  The agency plans to shut down 79 of its 89 nuclear facilities, including research reactors and test buildings, over 60 to 70 years due to aging and the huge costs needed for their continued operations under stricter safety standards.

According to the JAEA’s estimate, the cost to decommission the Tokai spent nuclear fuel reprocessing plant in Ibaraki Prefecture will be 770 billion yen.  But the overall cost would reach nearly 1 trillion yen if expenses on dealing with highly radioactive liquid waste, which is left after plutonium is extracted from spent fuel rods at the plant, are included.

The problem-plagued Monju prototype fast-breeder reactor in Tsuruga, Fukui Prefecture, cost taxpayers more than 1 trillion yen ($8.82 billion) despite running for only 250 days during its two-decade operation. ..But the JAEA currently has no plan on how to handle plutonium stored at the facilities. In addition, no decision has been made on what to do with radioactive waste from the 79 facilities that could fill more than 560,000 200-liter drums.

Excerpt JAEA: Closing 79 nuclear facilities will cost at least 1.9 trillion yen
THE ASAHI SHIMBUN, Dec. 27 2018

Diving into a Nuclear Pool

Leave a reply

United Kingdom: Specialist divers have completed their mission to deal with radioactive waste from Sizewell A Site’s nuclear fuel storage ponds, nearly two months ahead. The divers, who are shielded from radiation by the water in the ponds, successfully cut up and ‘size reduced’ all of the 35 waste storage containers left in Sizewell A’s ponds. They also cut up around 100 tonnes of other redundant equipment before removing all the radioactive sludge from the pond floor.

Conventionally, pond clean-out is done using remotely operated equipment to lift the whole radioactive skips  (waste containers) and other pond furniture clear of the water, exposing them to the air, where they are carefully cut and decontaminated. This process is slow with potential radiation dose risks for workers,” Magnox Sites said.  “Using this innovative underwater decommissioning technique, radiation levels for workers were around 20 times less than with conventional techniques of decommissioning the waste items in air,” it added. The diving technique also has a lower environmental impact, is quicker and more efficient and therefore cheaper.  The next phase of work is to take the waste out of the ponds where it will be treated and safely packaged. The ponds are set to be completely emptied and drained by the end of 2019.

The team of 12 nuclear divers was supplied by Underwater Construction UK Ltd. They tackled their first UK ‘nuclear dive’ at the Dungeness A Site in 2016 and arrived on site at Sizewell A in October 2017.

Sizewell A’s two 210 MWe Magnox gas-cooled reactors operated from 1966 until 2006. Defuelling began in 2009, with fuel removed from the reactors placed in the site’s used fuel storage ponds before being packaged in transport containers for shipment to the Sellafield complex for reprocessing. The final flask of fuel was shipped to Sellafield in August 2014. Sizewell A was declared completely fuel free in February 2015.

Excerpts from Divers Complete Radwast work at Sizewell A, World Nuclear News, Aug. 3,  2018

Swiss Nuclear Waste Disposal

Leave a reply

On November 27, 2016 Swiss voters will decide whether to turn off the country’s nuclear power stations after 45 years of activity. But what does dismantling a nuclear power plant involve? ….

On December 20, 2019, the Mühleberg nuclear power plant in canton Bern will definitely be disconnected from the grid. A new chapter in the history of Swiss nuclear energy will thus begin: the complete dismantling of a power plant…Situated around 15 kilometres from the Swiss capital Bern, the reactor has been in service since 1972 and provides 5% of the electricity used in Switzerland….

Once the fuel is extracted from the reactor core, it will be submerged in the so-called deactivation pool, where it will stay for several years.  Around 2024, the cooled uranium will be transported by lorry to the interim storage facility at Würelingen, canton Aargau.

It will then be possible to begin the real disassembly of the cement and steel structure, starting with the reactor core. This is the most complex phase…“Fifty years ago, when a power station was built, no one thought about dismantling it. The old plants were made in an extremely compact manner for reasons of cost and safety. Therefore there isn’t much space for the dismantling and decontamination,” …[D]eveloping robots.. [is one way] of improving efficiency and staff safety.

At Mühleberg, unlike what has been done in the United States for example, the so-called “fast” version will be used.“Dismantling this [boiling water] type of reactor is well-known and therefore we’ll be able to begin directly,” said Stefan Klute. “In other places the preference is to seal the plant for 40-50 years and wait for some of the residual radioactivity to decay naturally.”

In his opinion, there are many advantages to the more rapid option. “We don’t have to second-guess what the political situation will be in half a century – an impossible prediction in any case.

Dismantling the Mühleberg nuclear power station will generate around 200,000 tonnes of waste. Most of the material will be decontaminated directly in situ and recycled or disposed of in appropriate landfills.The whole operation should finish around 2034.

Excerpts from  Luigi Jorio The end of a Swiss nuclear power plant, Swissinfo.ch,  Nov. 17, 2016

Costs of Closing Down Nuclear Plants

Leave a reply

According to Callan Investment Institute, underfunded decommissioning costs could amount to $23 billion from investor-owned utilities.  The industry has already set aside $50 billion to fund specific trust funds designated exclusively for decommissioning expenses, mostly collected from ratepayers….

As part of the Nuclear Regulatory Commission commissioning and licensing of a power plant, the plant owners establish a trust fund, known as the Nuclear Decommissioning Trust, or NDT. The sole purpose of this trust fund is to provide funds for the cost to decommission the facility when that time comes. The owners contribute annually to the fund, in relationship to the percent ownership, based on projected costs and length of the license. The companies are the final backstop to shortfalls in funding to these trusts.

The origin of the capital for fund contributions is from customer rate cases – in other words, NDT funding is part of our monthly electric bills. Owners are required to review annually and submit every two years to the NRC both the fund balance and cost estimates for decommissioning. The NRC provides a formula of costs for operators to compare with the balances on the NDT, or the companies can file site-specific cost projections for each facility.

The total industry-wide decommissioning costs are estimated by Callan to be $80 billion….[For instance] Entergy, according to the study, their NDT could be short by about $2 billion and to make up this difference over the average life remaining of their licenses, management should be setting aside $186 million a year rather than the $39 million currently. However, ETR is not alone in the study. The industry contributed $315 million in 2013 when Callan calculates the amount should be closer to $1.6 billion. Below are some shortfall numbers for the five largest nuclear power generators,…

According to Callan, Exelon has potential net deficiencies of $7.7 billion including Constellation Energy; Duke has a potential net deficiency of $2.3 billion; Entergy of $2.0 billion; Dominion Resources  of $1.3 billion; and NextEra has a potential surplus of $208 million. Combined, the largest five producers of nuclear power have a potential decommissioning deficit of $13.1 billion, or 57% of the projected total industry-wide.

Excerpts from George Fisher, A $23 Billion Potential Shortfall For 27 Utilities With Nuclear Power Plants, Seeking Alpha,May. 15, 2015

Full Study (pdf)

Costs of Demolishing Nuclear Reactors

Leave a reply

/The International Energy Agency (IEA) said late in 2014  (pdf) that almost 200 of the 434 reactors in operation around the globe would be retired by 2040, and estimated the cost of decommissioning them at more than $100 billion.  But many experts view this figure as way too low, because it does not include the cost of nuclear waste disposal and long-term storage and because decommissioning costs – often a decade or more away – vary hugely per reactor and by country…. The IEA’s head of power generation analysis, Marco Baroni, said that even excluding waste disposal costs, the $100 billion estimate was indicative, and that the final cost could be as much as twice as high. He added that decommissioning costs per reactor can vary by a factor of four.Decommissioning costs vary according to reactor type and size, location, the proximity and availability of disposal facilities, the intended future use of the site, and the condition of the reactor at the time of decommissioning….

The U.S. Nuclear Regulatory Commission estimates that the cost of decommissioning in the United States – which has some 100 reactors – ranges from $300 million to $400 million per reactor, but some reactors might cost much more.  France’s top public auditor and the nuclear safety authority estimate the country’s decommissioning costs at between 28 billion and 32 billion euros ($32-37 billion).  German utilities – such as E.ON, which last month said it would split in two, spinning off power plants to focus on renewable energy and power grids – have put aside 36 billion euros. .  Britain’s bill for decommissioning and waste disposal is now estimated at 110 billion pounds ($167 billion) over the next 100 years, double the 50 billion pound estimate made 10 years ago.  Japanese government estimates put the decommissioning cost of the country’s 48 reactors at around $30 billion, but this is seen as conservative. Russia has 33 reactors and costs are seen ranging from $500 million to $1 billion per reactor.

Excerpt, Global nuclear decommissioning cost seen underestimated, may spiral, Reuters, Jan, 19, 2015

Mismanaging Nuclear Waste – Germany

Leave a reply

Inspectors in northern Germany have found that a third of barrels containing radioactive waste at a decommissioned nuclear plant are damaged, the Schleswig-Holstein Environment Ministry said on Thursday.  Vattenfall, the energy company which manages the Brunsbüttel site in Schlewswig-Holstein, reported that 102 of the 335 barrels stored in the site’s six underground chambers were corroded, leaking or had loose lids.  Some of the containers are so deformed that they can no longer be moved, as they no longer fit into the robotic gripping arms installed at the site, the inspectors reported.  “The chambers are secure and there is no danger for the personnel or the local population,” Vattenfall said in a statement released on Thursday,

The Brunsbüttel site harbours 631 barrels of nuclear waste in its six chambers, which have been used for storing waste since 1979. The nuclear power plant was decommissioned in 2011.  The barrels contain resin used for water filters, residue from contaminated water and various other types of waste.

So far, Vattenfall has only inspected four of the six chambers using remote cameras.  The chambers themselves are built from concrete and have walls over a metre thick to prevent radiation escaping into the surrounding environment.  The energy company has sent a proposal to the Schlewsig-Holstein Environment Ministry for making the storage facility more secure, including by installing dehumidifiers to slow corrosion, which has yet to be approved by government experts.  “The chambers [at Brunsbüttel] were supposed to be a temporary storage facility,” Vattenfall said in a statement on Thursday. “They weren’t designed to for long-term containment.”

It was originally planned to store the barrels at Brunsbüttel until they were moved to the ‘Konrad’ mine shaft site in Lower Saxony.This permanent storage facility was to be completed by the mid- to late 90s, but has been subject to successive delays. Completion dates in 2014 has been missed and a target of 2019 is also unlikely.  The latest estimate for completion is the start of the next decade.

One in three nuclear waste barrels damaged, The Local Germany, Oct. 10, 2014
