How to Exploit the Secrets of the Ocean: DARPA

PARC, A Xerox Company, announced on October 22, 2020,  it has been awarded a contract by the Defense Advanced Research Projects Agency (DARPA) for the next development phase in the Ocean of Things. Initially announced by DARPA in 2017, the Ocean of Things project is deploying small, low-cost floats in the Southern California Bight and Gulf of Mexico to collect data on the environment and human impact. This includes sea surface temperature, sea state, surface activities, and even information on marine life moving through the area.

Xerox Ocean Float is Equipped with Camera, GPS and other sensors. Ocean of Things

“Oceans cover more than 70 percent of the earth’s surface, but we know very little about them,” said Ersin Uzun, vice president and general manager of the Internet of Things team at Xerox. “The floats gather data that we could never track before, enabling persistent maritime situational awareness.” Each solar-powered drifter has approximately 20 onboard sensors, including a camera, GPS, microphone, hydrophone, and accelerometer. The different  sensors can provide data for a broad array of areas including ocean pollution, aquafarming and transportation routes…Among other things, the float needed to be made of environmentally safe materials, be able to survive in harsh maritime conditions for a year or more before safely sinking itself, and use advanced analytic techniques to process and share the data gathered…PARC built 1,500 drifters for the first phase of the project and will deliver up to 10,000 that are more compact and cost-effective for the next phase.

Excerpt from DARPA Awards PARC Contract to Expand Ocean Knowledge, XEROX Press Release, Oct. 22, 2020

A Brand New World: Mapping the Ocean Floor

Mapping of the ocean floor may expand under an order signed by President Donald Trump on in  November, 2019 to create a federal plan to explore U.S. coastal waters. The announcement…comes amid growing international interest in charting the sea floor as unmanned aquatic drones and other new technologies promise to make the work cheaper and faster. The maps, also created by ship-towed sonar arrays, are crucial to understanding basic ocean dynamics, finding biological hot spots, and surveying mineral, oil, and gas deposits.

But much of the ocean floor remains unmapped; an international campaign called Seabed 2030 aims to map all of it in detail by 2030. Such maps cover just 40% of the 11.6 million square kilometers in the U.S. exclusive economic zone, which extends 320 kilometers from the coasts of all U.S. states and territories—an area larger than the total U.S. land mass. Today, those maps are a hodgepodge drawn from government, industry, and academic research, says Vicki Ferrini, a marine geophysicist at Columbia University’s Lamont-Doherty Earth Observatory in Palisades, New York. The federal plan, she says, could be a “game changer.”

Excerpts from  United States to Survey Nearby Sea Floor, Science, Nov. 29, 2019, at 6469

Black Operations are Getting Blacker: US Military

Heterogeneous Collaborative Unmanned Systems (HCUS), as these drones will be known, would be dropped off by either a manned submarine or one of the navy’s big new Orca robot submersibles.

Logo for Orca Submarine by Lockheed Martin

They could be delivered individually, but will more often be part of a collective system called an encapsulated payload. Such a system will then release small underwater vehicles able to identify ships and submarines by their acoustic signatures, and also aerial drones similar to the BlackWing reconnaissance drones already flown from certain naval vessels.

BlackWing

Once the initial intelligence these drones collect has been analysed, a payload’s operators will be in a position to relay further orders. They could, for example, send aerial drones ashore to drop off solar-powered ground sensors at specified points. These sensors, typically disguised as rocks, will send back the data they collect via drones of the sort that dropped them off. Some will have cameras or microphones, others seismometers which detect the vibrations of ground vehicles, while others still intercept radio traffic or Wi-Fi.

Lockheed Martin Ground Sensor Disguised as Rock

HCUS will also be capable of what are described as “limited offensive effects”. Small drones like BlackWing can be fitted with warheads powerful enough to destroy an SUV or a pickup truck. Such drones are already used to assassinate the leaders of enemy forces. They might be deployed against fuel and ammunition stores, too.

Unmanned systems such as HCUS thus promise greatly to expand the scope of submarine-based spying and special operations. Drones are cheap, expendable and can be deployed with no risk of loss of personnel. They are also “deniable”. Even when a spy drone is captured it is hard to prove where it came from. Teams of robot spies and saboteurs launched from submarines, both manned and unmanned, could thus become an important feature of the black-ops of 21st-century warfare.

Excerpts from Submarine-launched drone platoons will soon be emerging from the sea: Clandestine Warfare, Economist, June 22, 2019

Militarization of the Deep Sea

U.S. military researchers are moving forward with a program to hide ruggedized electronic devices at the bottom of the world’s oceans that when called on will float to the surface to jam, disrupt, and spy on enemy forces.  Officials of the U.S. Defense Advanced Research Projects Agency (DARPA) in Arlington, Va., this week released a formal solicitation (DARPA-BAA-14-27) for the second and third phases of the Upward Falling Payloads (UFP) project to hide sensors and other devices on the ocean floor that will last for as long as five years concealed at depths to 20,000 feet.

Last summer (2013) DARPA awarded UFP phase-one contracts to Sparton Electronics of De Leon Springs, Fla., and to Zeta Associates Inc. in Fairfax, Va., to develop conceptual designs of a future system with the potential to launch sensors, electronic jammers, laser dazzlers, and other devices surreptitiously and quickly in any of the world’s maritime hot spots…

Sparton and Zeta experts designed UFP concepts that not only would float sensors to the ocean’s surface, but also potentially launch a wave of distracting light strobes, blinding lasers, electronic warfare jammers, or other kinds of non-lethal weapons able to pop up without warning in the middle of an adversary’s naval battle group.

“The goal is to support the Navy with distributed technologies anywhere, anytime over large maritime areas. If we can do this rapidly, we can get close to the areas we need to affect, or become widely distributed without delay,” says Andy Coon, the DARPA UFP program manager. “To make this work, we need to address technical challenges like extended survival of nodes under extreme ocean pressure, communications to wake-up the nodes after years of sleep, and efficient launch of payloads to the surface.”…

DARPA moves forward with project to lay sea-based electronic ambushes for enemy naval forces,  Indian Defence, March 27, 2014

See also https://www.fbo.gov/index?s=opportunity&mode=form&id=234431690a8c824d7b67a24d95596e7c&tab=core&tabmode=list&=
